| Load Capacity | 3 kg (6.6 lb) |
|---|---|
| Travel Range | Up to 50 mm |
| Fine Tuning Resolution | 200 nm/turn to 20 micron/turn (adjustable) |
| Coarse Tuning Resolution | 500 micron/turn |
| Construction | Stainless steel, or aluminum alloy (black anodized) |
| Guiding Structure | Frictionless flexure |
CALL TOLL FREE
CALL: 1-800-314-3332
Features:
- Long travel translation stage with resolution in nanometer range
- Coarse tuning combined with fine tuning in the same stage
- Manually driven
- Pitch, yaw, and roll totally eliminated
Applications:
- Nano-metric linear drives
- Laser cavity tuning
- Interferometry
- Nano-metrology
- Fiber optic alignment
- Wafer and mask positioning
- Inspection systems
