Model VS3SD-.5-D-PL, High Precision Positioning Stage
UnitUS Standard
SeriesVS3
IMInch
Work Surface3.5 X 3.5
Travel0.5"
US Travel Filter0 to 2"
Product TypeCROSSED ROLLER RAIL
DriveSIDE
Actuator100 TPI ADJUSTMENT
PosiLockYES
Capacity116 lbs
US Capacity Filter111 to 165 lbs
M137.04
M299.76
M3104.72
Accuracy0.0001"
Repeatability0.0001
CofFriction0.002
