Model VBM3SD-12.5-PL, High Precision Positioning Stage
UnitMetric
SeriesVBM3
Work Surface76 X 76
Travel12.5 mm
Metric Travel Filter0 to 50 mm
Product TypeBALL BEARING
DriveSIDE
ActuatorMICROMETER
PosiLockYES
Capacity26 kg
Metric Capacity Filter0 to 55 kg
M13.65
M22.85
M33.18
Accuracy0.001 mm
Repeatability0.0005
CofFriction0.002
