Model R451SD-XYZ, Side Drive Positioning Stage
capacityz20 lbs
capacityxy40 lbs
UnitUS Standard
Series450SD, R450SD
IMInch
Travel1.00"
US Travel Filter0 to 2"
Capacity40 lbs
US Capacity Filter0 to 55 lbs
Accuracy0.0001"
Product TypeCrossed Roller
M117.02"
M217.02"
M317.02"
C.69"
D1.12"
M1.312"
CBORE6 - 32
Thread6 - 32
Holes6
O.875"
P1.008"
L4.51"
Hx.75"
Hy1.50"
SLOT.50 x 1.00
Capacity XY40 lbs
Capacity Z20 lbs
Work Surface1.75 X 1.75
Through Hole6
W2.55 lbs
Axis(XYZ) Triple Axis
Option LM1
Option PL1
Option PL Price150
OrientationSide Drive
