Model NBT-3255A-180M, Crossed Roller Slide Tables (Aluminum) Metric
UnitMetric
SeriesNBT-3000AM
Travel180 mm
Metric Travel Filter151 to 200 mm
Capacity310 kg
Metric Capacity Filter0 to 500 kg
L255 mm
Base Holes8
U235 mm
W135 mm
Carriage Holes18
M8X25 mm
N27.5 mm
P25 mm
JM5
K10.5 mm
R10 mm
S40 mm
D10.1 mm
d_small5.8 mm
A28 mm
B60 mm
C9 mm
Accuracy0.0025 mm
Product TypeCrossed Roller
M138
M2170.7
M3179.22
Carriage Material TypeAluminum
Rail Material TypeSteel
