Model LRSA1-75-C005-XYZ, Mini Posi-Drive Stages
UnitMetric
SeriesLRSA1
Travel75 mm
Metric Travel Filter51 to 100 mm
Capacity13.6 kg
Metric Capacity Filter0 to 25 kg
Accuracy0.003 mm
Product TypeBall Slide
M17.34
M215.59
M316.37
A154.2
B101.6 mm
C52.6
D85 mm
H85 mm
Axis(XYZ) Triple Axis
